| Main Feature |
| BRAND |
MOSDAR |
| ORIGIN |
CHINA |
| MODEL |
TIG-250S |
| INPUT POWER |
AC 220V±15% |
| RATED INPUT CAPACITY (KVA) |
6.53 |
| POWER FACTOR |
0.74 |
| RATED OPEN CIRCUIT VOLATGE |
66 |
| EFFICIENCY (%) |
85 |
| RATED MAXIMUM OUTPUT (A/V) |
220A/18.8V |
| WELDING CURRENT (A) |
10~220 |
| POST-FLOW TIME (S) |
2~10 |
| ARCING MODE |
High frequency |
| OUTPUT CHARACTERISTIC |
CC (constant current) |
| RATED DUTY CYCLE (%) |
35 |
| WELDING CURRENT (A) |
50~250 |
| WELDING TIME (MS) |
1~900 |
| WELDING INTERVAL (S) |
0.1~10 |
| OPERATING TEMPERATURE (°C) |
High frequency |
| STORAGE TEMPERATURE (°C) |
-10~+40 |
| HUMIDITY (%) |
≤90 (no water condensation) |
| COOLING MODE |
IP21S |
| WEIGHT (KG) |
Forced air cooling |
